Chipset | Intel Q75 Express |
Processor | Intel 3rd generation core i7 processors: Intel Core i7-3770 processor: Intel 3rd generation core i5 processors: Intel 2nd generation core i3 processors: Intel Pentium processors: Intel PentiumG870 processor Intel PentiumG860 processor Intel PentiumG640 processor
Intel Celeron processors: Intel Celeron G550 processor Intel Celeron G540 processor Intel Celeron G460 processor
|
Graphics | Integrated on all models (depends on processor): Intel HD Graphics: Basic, 2000, 2500, 4000 Optional discrete graphics solutions: AMD Radeon HD 6350 (512MB) PCIe x16 (includes a DMS-59 to Dual VGA Y Cable) AMD Radeon HD7450 (1GB) PCIe x16 (includes a DVI to VGA adapter cable) NVIDIA NVS 300 (512MB) PCIe x16 (Includes a DMS-59 to Dual VGA Y Cable) NVIDIA NVS 310 (512MB) PCIe x16
Adapters and cables: DisplayPort to DisplayPort cable DisplayPort to DVI-D adapter DisplayPort to HDMI adapter DisplayPort to VGA adapter
|
Storage | SATA hard drive: 250 GB, 7200 rpm, SATA 6.0 Gb/s, SMART IV, 3.5 in 500 GB, 7200 rpm, SATA 6.0 Gb/s, SMART IV, 3.5 in 1TB, 7200 rpm, SATA 6.0 Gb/s, SMART IV, 3.5 in
SATA self-encrypting drive: 320 GB, 7200 rpm, SATA, 3.5 in SATA self-encrypting Solid State Drive (SSD): 256 GB, SATA, 3.5 in SATA Solid State Drive (SSD): 120 GB, SATA (with 3.5 in adapter) 128 GB, SATA (with 3.5 in adapter)
Optical disc drive: DVD-ROM SuperMulti DVD writer Blu-ray writer
Media card reader: 22-in-1 |
Memory1 | Type: DDR3 non-ECC Up to 1600 MT/s
Maximum: 32 GB Number of slots: 4 |
Networking/Communications | Ethernet (RJ-45): Wireless: 802.11b/g/n PCIe x1 (optional) |
Audio/Multimedia | High Definition Audio with Realtek ALC221 codec (all ports are stereo) Microphone2 and headphone front ports (3.5 mm) Line-out and Line-In rear Ports2 (3.5 mm) Multi-streaming capable2 Internal speaker (standard) Thin USB power speakers USB HD 720P business webcam Business headset
|
Keyboards and pointing devices | Keyboard: PS/2 keyboard USB keyboard USB Smart Card (CCID) keyboard USB and PS/2 washable keyboard Wireless keyboard and mouse combo
Mice: |
Power | 240 W, active PFC, 90% high efficiency 240 W active PFC, standard efficiency
|
Ports | I/O ports – standard: 4 – USB 3.0 (rear) 4 – USB 2.0 (front) 2 – USB 2.0 (rear) 1 – Serial RS-232 compatible 2 – PS/2 (color-coded support for keyboard (purple) and mouse (green) 1 – VGA 1 – DisplayPort 1.1 1 – Microphone and headphone (front) 1 – Audio-in and Audio-out (rear) 1 – RJ-45 (accesses the integrated network interface controller)
I/O ports – optional |
Bays | 3.5 in external (For Media Card Reader unless used for secondary data drive) – 1 each 5.25 in external – 1 each 8.19 in depth 3.5 in internal HDD – 1 each
|
Slots | PCI (5 volt): 1 each 2.5 in low profile 6.6 in length 25 W maximum power
PCI Express x1 (2.0): 2 each 2.5 in low profile 6.6 in length 10 W maximum power
PCI Express x16 (3.0 – Primary): 1 each 2.5 in low profile 6.6 in length 25 W maximum power
|
